Launch from the Baikonur Cosmodrome; landing
400 km southwest of Karaganda.
Vasili
Lazarev became first Soviet
Soyuz
Commander,
who was both a military pilot and a medical doctor.
Soyuz 12 was a
test flight of the new designed
Soyuz capsule. The crew capacity of the capsule
had been decreased from three to two cosmonauts to allow for space suits to be
worn during launch, reentry, and potentially hazardous maneuvers.
As
the first manned test of the new version of the
Soyuz ferry craft,
Soyuz 12 was to have flown to a
Salyut station. But the failures of
Salyut 2 and Kosmos 557 in the months previous meant
there was no station for the craft to dock to. The service module had no solar
panels, carrying batteries for power instead, which limited the flight to about
two days, enough time for a journey to and from a space station.
A
multispectral camera in the orbital module was used in coordination with
aircraft to photograph Earth. The intention was to survey crop and forest
conditions, it was reported. The cosmonauts also tested using a Molniya 1
satellite to communicate with ground stations when out of range.
The
Soyuz spacecraft is composed of three elements
attached end-to-end - the Orbital Module, the Descent Module and the
Instrumentation/Propulsion Module. The crew occupied the central element, the
Descent Module. The other two modules are jettisoned prior to re-entry. They
burn up in the atmosphere, so only the Descent Module returned to Earth.
The
deorbit burn lasted 188 seconds. Having shed two-thirds of its mass, the
Soyuz reached Entry Interface - a point 400,000 feet
(121.9 kilometers) above the Earth, where friction due to the thickening
atmosphere began to heat its outer surfaces. With only 23 minutes left before
it lands on the grassy plains of central Asia, attention in the module turned
to slowing its rate of descent.
Eight minutes later, the spacecraft was
streaking through the sky at a rate of 755 feet (230 meters) per second. Before
it touched down, its speed slowed to only 5 feet (1.5 meter) per second, and it
lands at an even lower speed than that. Several onboard features ensure that
the vehicle and crew land safely and in relative comfort.
Four parachutes,
deployed 15 minutes before landing, dramatically slowed the vehicle's rate of
descent. Two pilot parachutes were the first to be released, and a drogue chute
attached to the second one followed immediately after. The drogue, measuring 24
square meters (258 square feet) in area, slowed the rate of descent from 755
feet (230 meters) per second to 262 feet (80 meters) per second.
The main
parachute was the last to emerge. It is the largest chute, with a surface area
of 10,764 square feet (1,000 square meters). Its harnesses shifted the
vehicle's attitude to a 30-degree angle relative to the ground, dissipating
heat, and then shifted it again to a straight vertical descent prior to
landing.
The main chute slowed the
Soyuz to a descent rate of only 24 feet (7.3 meters)
per second, which is still too fast for a comfortable landing. One second
before touchdown, two sets of three small engines on the bottom of the vehicle
fired, slowing the vehicle to soften the landing.
A large object was
jettisoned when the craft was preparing for retrofire. The object remained in
orbit for 116 days, landing 400 km southwest of Karaganda.
